Side Outlet Elbows, beaded
Enlargement Product Name : Side Outlet Elbows, beaded
Product Description
Product Name: Side Outlet Elbows, beaded
Item Number: 1221
Class: 150LBS
Material: ASTM A197, ASTM A47
Dimension: ASME B16.3 B16.14
Galvanization: ASTM A153
Thread: B1.20.1
Product Character
|
Size |
Dimensions |
|
|
|
||
|
(mm.) |
||
|
Inch |
mm |
A |
|
1/2" |
15 |
27 |
|
3/4" |
20 |
32 |
|
1" |
25 |
36 |
|
1.1/4" |
32 |
43 |
|
1.1/2" |
40 |
49 |
|
2" |
50 |
57 |
